The IX-DVF-2RA is a SIP compatible IP Video Emergency Door Station. It is ADA compliance with one emergency call button.
Model: IX-DVF-2RA Door Station
The Aiphone IP Video Door station is compatible with the IX series, It is UL certified.
SIP - Peer to Peer- Emergency
Door Station Features
- Use SIP to integrate with Cisco Unified Call Manager and answer calls off-site
- ONVIF Profile S Compliant
- Both Call and Emergency call buttons
- ADA compliant raised lettering and Braille signage
- 802.3af PoE with PoE pass through (802.3at Type 2 PoE )
- 1.23 megapixel fixed color video camera
- Camera vertical adjustment 15, 0, or -8 (manual)
- White LED for low light illumination
- Capture and store the audio and video of active conversations on a microSD card (not provided by Aiphone)
- IP65 rated, weather resistant
- Stainless steel faceplate
- 2 contact outputs
- 6 trigger inputs
- 2-year warranty!
Shop CTC Communications for best deals on
Specifications
- Power Source
- PoE (IEEE 802.3af class 0)
- Power Draw
- 5.28 Watts
- Camera
- " CMOS 1.23 megapixel
- Min. illumination
- 5 lux
- Audio Codec
- G.711 (-law, A law), G.722
- Video Codec
- H.264/AVC, motion JPEG
- Protocols
- IPv4, IPv6, TCP, UDP, SIP, HTTP, HTTPS, RTSP, RTP, RTCP, IGMP, MLD, SMTP, FTP, DHCP, NTP, DNS
- Port Security
- IEEE 802.1X
- Operating Temp
- -40 - 140F (-40 - 60C)
- Ingress Protection
- IP65
- Impact Protection
- IK08
- Dimensions
- 11-1116" H x 7" W
- Mounting
- Flush mounted with included back box, or surface mount with the SBX-IDVFRA Stainless Steel surface mount box. Also compatible with the WB-CA, WB-HA, WB-CE, and WB-HE Emergency wall boxes or modular towers.
